LUXCOMB Windsor Ceiling LED
P54 ceiling or wall mount lights are the ideal solution for humid areas, corridors, garages, workshops and many other places...
The 12W or 18W IP54 Windsor LED decorative fitting consists of a white polycarbonate base, diffuser and bezel. Suited ideally to bathrooms, kitchens and communal areas where energy savings and aesthetics are particularly important. A Versatile Surface Mounted Luminaire able to both wall or ceiling mounted.
Try it and you’ll be convinced !
LUXEON 3030 2D LUMILED is the first hot-color targeted mid power LED. Hot-color targeting ensures that the LEDs are within color target at application conditions 85°C. More information are available on the Lumileds website at www.lumileds.com
Professional SERIES CEILING / WALL 12W OR 18W IP54
| Model | Product number | Angle (degrees) | CCT (K)** | Ra | Power (W) | Lumen (lm) | Dimensions (mm) |
|---|---|---|---|---|---|---|---|
| 1412 | SMLW122D | 165 | 4000 | 80+ | 12 | 1160 | Ø 320x90 |
| 1433 | SMLW122D-E* | 165 | 4000 | 80+ | 12 | 1160 | Ø 320x90 |
| 1434 | SMLW122D-S* | 165 | 4000 | 80+ | 13 | 1160 | Ø 320x90 |
| 1435 | SMLW122D-X* | 165 | 4000 | 80+ | 13 | 1160 | Ø 320x90 |
| 1418 | SMLW182D | 165 | 4000 | 80+ | 18 | 1640 | Ø 320x90 |
| 1443 | SMLW182D-E* | 165 | 4000 | 80+ | 18 | 1640 | Ø 320x90 |
| 1444 | SMLW182D-S* | 165 | 4000 | 80+ | 19 | 1640 | Ø 320x90 |
| 1445 | SMLW182D-X* | 165 | 4000 | 80+ | 19 | 1640 | Ø 320x90 |
| 1413 | SMLW132D (version 2013-2015) replaced by SMLW122D | 165 | 4000 | 80+ | 13 | 1160 | Ø 320x90 |
| 1420 | SMLW202D (version 2013-2015) replaced by SMLW182D | 165 | 4000 | 80+ | 20 | 1640 | Ø 320x90 |
| 1414 | SMLW122D | 165 | 4000 | 80+ | 12/18 | 1160/1640 | Ø 320x90 |
E* : Emergency version (three hour duration minimum 150 lm)
S* : Motion Sensor version (Sensor version, the sensor has is a supplementary consumption of 1W standby/operation)
X* : E + S
Optional IP65 Fixing Kit
Wherever you’re are Europe, in the USA, in Asia - the new offers a wide cross section range at the mains end, enabling it to be perfectly suited for use in America as well as in Japan. The Cross section range: 0.5 to 2.5 mm² (AWG: 18 to 12, Japan: 0.8 to 2.0 mm). The CAGE CLAMP®S connection allow solid, stranded and fine-stranded conductors (no preparation necessary).
OPTION KIT FIXATION IP65
Model 1403
