LUXCOMB LED GU10/MR16
SPECIFICATIONS
- User Safe, the bulbs comply with CE / IEC standards and have a reliable electrical shock protection
- Die Cast Aluminum Heat Sink and a special heat conductive plastic shell for efficient heat dissipation (following the model)
- Energy efficient LED COB technology
- Resistant to shock and vibration, maintenance free
- No flicker effect
Professional SERIES - GU10
| Model | Product number | Angle (degrees) | CCT (K)* | Ra | Power (W) | Lumen (lm) |
|---|---|---|---|---|---|---|
| 400 | GU10-WW-HC0-005-30-1 | 30 | 2700 | 80 | 5 | 450 |
| 401 | GU10-WW-HC0-005-60-1 | 60 | 2700 | 80 | 5 | 510 |
| 411 | GU10-PW-HC0-005-60-1 | 60 | 4000 | 80 | 5 | 470 |
| 420 | GU10-WW-HC0-006-30-2 | 30 | 2700 | 80 | 6 | 550 |
| 421 | GU10-WW-HC0-006-60-2 | 60 | 2700 | 80 | 6 | 550 |
| 441 | GU10-WW-HC0-005-60-1D | 60 | 2700 | 80 | 5 | 450 |
Professional SERIES - MR16
| Model | Product number | Angle (degrees) | CCT (K)* | Ra | Power (W) | Lumen (lm) |
|---|---|---|---|---|---|---|
| 402 | MR16-WW-HC0-005-30-1 | 30 | 2700 | 80 | 5 | 430 |
| 403 | MR16-WW-HC0-005-60-1 | 60 | 2700 | 80 | 5 | 430 |
| 413 | MR16-PW-HC0-005-60-1 | 60 | 4000 | 80 | 5 | 450 |
| 433 | MR16-PW-HC0-006-60-0 | 60 | 4000 | 80 | 6 | 530 |
Compatibility of LUXCOMB 230V dimmable GU10 (Model 441)
| Brand | Part Number | Compatable ? |
|---|---|---|
| BERKER | 286710 | Yes |
| BUSCH- YEAEGER | 6523U | Yes |
| BUSCH- YEAEGER | 6513U-102 | Yes |
| CLIPSAL | 32E450 | Yes |
| ELEC. TRAFO | Tradim 2482 | No |
| ERCO | Yes | |
| FELLER | 40600RL | Yes |
| FELLER | 40420RLC | Yes |
| FELLER | 40300RC | Yes |
| GOVENA | METPROI4N | Yes |
| LAMPE | AD500/300RL | Yes |
| LEGRAND | 670 81 | No |
| LEGRAND | 670 84 | No |
| LEGRAND | 670 85 | No |
| LUTRON | Yes | |
| MARBO | C0003 | Yes |
| MERTEN | 5734 | Yes |
| MK | K1501 WHILV | Yes |
| PANASONIC | M935S | Yes |
| SCHNEIDER | S520515 | Yes |
| SCHNEIDER | 82090 | Yes |
| SCHNEIDER | SBD315RC | Yes |
| SIEMENS | 5TC8 284 | Yes |
| SIEMENS | 5TC8 256 | Yes |
| VARILIGHT | V-Pro 60669-2-1 | Yes |
| VARILIGHT | JQP401W 94816 | Yes |
| VARILIGHT | IDQI401MS | Yes |
| YOKIS | MTV500E | No |
Please find all our models on www.luxcomb.com
* Colour Temperature range is available in 2700-6500K, for more details please contact us
